RD500
HEAVYUSER|ALU-CORE-DRILLSTAND
up to Ø 500 mm drilling range
up to Ø 500 mm drilling range
-
Max. Drill-Ø500 mm
-
Travel Length600 mm
-
CarriageRoller-/Sliding carriage
-
Weight26.5 kg
ltem number: 0295 500 6300
-
FEATURES
![Quick coupler for extension column]()
Quick coupler for extension column![Fastening device for drill-carriage]()
Fastening device for drill-carriage -
TECH DATA TABLE
• Heavy User core drilling machine with roller
carriage
• Travel length „endless-prolongable“ by quick
coupler and separate extension column
• 2-speed feeding by planetary gear (1:3,5
reduction)
• Drill range up to 500mm
• backside support with transport handle
• Stepless angle drilling device up to 45°
• Negative angle drilling device up to 6°
Specifications RD500 Max. Drill diameter Ø 500 mm Column Aluminum Stroke 600 mm (endless by extension) Angle drilling device positive/negative Base anchor base Carriage Roller Carriage Dimensions (LxWxH) 364 x 300 x 1.056 mm Weight 26,5 kg Motor connection Mounting plate Order number 0295 500 6302 -
